| Engine Type |
1 cyl |
| Displacement |
72cc |
| Bore x Stroke |
54 x 31.5 mm (2.13 x 1.24 in) |
| Prop Shaft Horsepower |
2.5hp at 5500 rpm |
| Full Throttle RPM Range |
5250 ~ 5750 |
| Alternator Output at W.O.T. |
N/A |
| Compression Ratio |
8.8:1 |
| Fuel Induction System |
Carb |
| Weight † |
17 kg (37 lbs) – 20 kg (40lbs) |
| Recommended Fuel |
Octane 87 |
| Recommended Engine Oil |
Yamalube® 4M (See owner’s manual) |
| Recommended Fuel Filtration |
N/A |
| C.A.R.B. Rating |
2-Star |
| Exhaust |
Above Propeller |
| Intake |
2 |
| Ignition |
TCI |
| Spark Plug |
CR6HSB |
| Alternator Output |
N/A |
| Starting System |
Manual |
| Lubrication |
Splash |
| Engine Oil Capacity |
0.35L |
| Recommended Cooling |
Thermostatic Control |
| Ethanol Blend Limit |
10% Maximum |
| Gear Ratio |
2.01:1 |
| Gear Shift |
Forward, Neutral |
| Shaft Length |
15″ – 20″ |
| Degree of Tilt |
79° |
| Degree of Trim |
-4° through +16° |
| Dry Weight |
15″ shaft / 17 kg (37 lbs), 20″ shaft / 20 kg (40 lbs) |
| Mounting Centers |
N/A |
| Steering Angle (maximum) |
360° from center, either direction |
| Warranty |
Limited 3-Year Pleasure, 3-Year Government, 1-Year Commercial |
